• Kiểu loa: loa passive 2 loại driver

    Acoustical data

• Usable Bandwidth [-10dB]: 65 - 20.000 Hz
• Frequency Response [-6 dB]: 70 - 19.600 Hz
• Max SPL: 120  dB
• Type HF: Compression Driver
• HF voice coil:  1“
• LF: 8"
• LF voice coil: 1.5"
• Crossover Frequency (passive):  2300 Hz (24 dB/oct.)
• Horizontal Dispersion: asymmetrical 85° up / 120°down
• Vertical Dispersion: 85° (+25/ -60°)

    Amplifier

• Amp Technology: Custom Made
• Amp Class: Class D - Passice cooling (convection)
• Power Peak: 260 W

    Processor

• Controller: DSP 28/56 bit- 48 kHz
• Limiter: Peak, RMS, Thermal
• Controls: Volume, Audio Input Sensitivity, DSP Preset

    Input

• Main Connection: VDE
• SignalInput: Balanced 1xCombo IN (MIC/LINE)
• Signal Output: (Balanced) 1xXLR OUT (LINK)

    Mechanics

• Housing: Polypropylene
• Grille: Full Metal Grille
• Handles: 3 (2 on side 1 on top)
• Pole mount: 36 mm
• Kích thước: 243 x 443 x 231 mm
• Cân nặng: 6.6 kg
• Angles Up: Double wedge angle 45°
