Thông số kỹ thuật

Number 2
Basket Ø 7" (175 mm)
Voice Coil Ø 1.5" (38 mm)
Cone Material Carbon/Rohacell/Glass Fiber

TWEETER

Number 1
Type X-ART
Diaphragm Area 4 inch² (2420 mm²)
Equiv. Diaphragm Ø 2" (56 mm)
Velocity Transform Ratio 4:1
Diaphragm Weight 0.17 g

BUILT-IN AMPLIFIERS

Woofer 1
Type PWM
Amp. Power RMS / Music 100 W / 150 W
Subwoofer 1
Type PWM
Amp. Power RMS / Music 100 W / 150 W
Tweeter 1
Type A/B
Amp. power RMS / music 50 W / 75 W

CONTROL PANEL

Input Sensitivity -∞ to +14 dB
High Shelf EQ > 5 kHz ±6 dB
Low Shelf EQ < 300 Hz ±6 dB
Tweeter Gain ±4 dB

INPUT CONNECTORS

Analog XLR / RCA

GENERAL DATA

Frequency Response 38 Hz - 50 kHz
THD 90 dB / 1 m > 100 Hz ≤0.5 %
Max. SPL with sine wave acoustic 100 Hz to 3 kHz at 1 m ≥114 dB
Max. SPL per pair at 1 m ≥122 dB
Crossover Frequencies 400 / 3000 Hz
Input Impedance 30 kOhm
Panel Front
Weight 28.2 lb (12,8 kg)
Magnetically Shielded No
Height x Width x Depth 9.5" (235 mm) x 21" (530 mm) x 11" (280 mm)
Delivery Contents Power cord, manual
Mã sản phẩm: AD2461
Tình trạng: Còn trong kho

Loa kiểm âm ADAM A77X chính hãng

30,300,000đ
- +
